Technical data
| Seat width | 54.6 cm |
|---|---|
| Seat height | 48.3 cm |
| Seat depth | 61 cm |
| Body height | approx. 160 - 180 cm |
| Height | 61 cm |
| Slope | approximately 158° degrees |
| Volume weight comfort foam | 17 (kg/m³) |
| Hardness comfort foam (backrest) | 40 |
| Hardness of comfort foam (backrest) | H2 |
| Volume weight comfort foam (armrest) | 55 (kg/m³) |
| Hardness comfort foam (armrest) | 50 |
| Hardness of comfort foam (armrest) | H3 |
| Volume weight of comfort foam (seat surface) | 32 (kg/m³) |
| Hardness comfort foam (seat surface) | 50 |
| Hardness Integrd comfort foam (seat surface) | H3 |
| Chair height | 111.8 cm |
| Chair width | 74.9 cm |
| Armchair length in rest position | 170.2 cm |
| Maximum load | 150 kg |
| Space requirement | 180 x 75 cm |
| Weight | 56 kg |
| Operating voltage | 230 volts |
| Control voltage | 24 volts |
| Power consumption | 6 amp |
| Rated voltage | 100-240 V |
| Rated frequency | 50-60 Hz |
| Dimensioning recording | 345 W |
| Place of installation | Closed rooms |
| Operating mode 1) at max. nominal load | 10 % / max. 5 switching cycles |
| max. adjustment speed 2) | 44 mm/s |
1) Operating mode = intermittent operation AB 2 min/18 min, i.e. run for a maximum of two minutes under rated load, after which a break of 18 minutes must be observed. Otherwise
the function may fail!
2) Adjustment speed = speed at which the fork head can be moved without load (the adjustment speed varies according to the load)
